ISDT K4 Lipo Charger
₹18,699.00
The ISDT-CHRG-972 (K4 Smart Dual Charger) is a powerful, intelligent, and highly efficient dual-channel charger designed for serious RC hobbyists, drone pilots, and professionals. With support for both AC and DC input, the charger offers unparalleled flexibility whether you're in the workshop or out in the field. It delivers a maximum of 600W per channel in DC mode (total 1200W) and 400W total in AC mode, allowing for fast, simultaneous charging of two battery packs.
Choose Quantity
Product Details
Features
- Dual Fast Charging Channels (AC & DC supported)
- Independent Dual Output Channels (No interference)
- BattAir New Generation Interconnection Technology
- Parallel Charging Supported
- STRONG PERFORMANCE with up to 600W/channel
- AC/DC Dual Mode for flexible power input
- Intelligent temperature & voltage monitoring
- Compact yet high-power design
Technical Specifications
- Max charging power: AC 400W / DC 600W x2
- Input voltage: AC 100240V / DC 1034V
- Charging current: 0.2–20A x2
- Output voltage: DC 1–34V
- Max input current: 45A
- Balance current: Max 1.5A/cell
- Supported battery types: LiFe, Li-Ion, LiPo (1–8S), LiHv (1–7S), Pb (1–14S), NiMH (1–18S)
- Dimensions: 182 × 177 × 55mm
- Weight: 1226g (2.7lb)
- Dual-channel operation with independent circuits
- AC/DC dual-mode support
- Parallel charging supported
- Intelligent BattAir technology support
- High-resolution display with real-time charge data
- Overcurrent, overvoltage, and reverse polarity protection
Additional Details
- Dual independent channels for simultaneous charging
- AC/DC dual mode operation
- Parallel charging supported
- BattAir intelligent battery interconnection
- Smart charging with automatic current adjustment
- High-definition display (user interface)
- Compact and portable design
- Comprehensive protection: Over-voltage, Over-current, Over-temp
Package Includes:
- 1× ISDT K4 Smart Dual Charger
- 1× AC Power Cable
Frequently Asked Questions
Q1: What types of batteries are compatible with the ISDT K4 charger?
A: The charger supports LiFe, Li-Ion, LiPo (1–8S), LiHv (1–7S), Pb (1–14S), and NiMH (1–18S) battery types.
Q2: Can I charge two different battery types simultaneously?
A: Yes, the charger has dual independent channels, allowing you to charge two different battery packs (even of different types or cell counts) at the same time.
Q3: What is the maximum charging power in AC and DC mode?
A: In AC mode, the charger provides up to 400W. In DC mode, each channel can deliver up to 600W, totaling 1200W.
